Technical Specifications:
High or Low Temperature upright cabinets and counters, cold stores, plug-in display cases, control panels, heated cabinets.
|
Control Range |
-50÷120°C |
|
Resolution |
0.1 / 1 °C; °F |
|
Accuracy |
NTC10K: <±0.3°C (-40.0÷70.0°C) PTC1000: <±0.5°C (-50÷120°C) |
|
Sensor type |
Selectable NTC10K standard mod. SN4B20P1/P2 or PTC1000 |
|
Power supply |
230V~ ±10% 50÷60Hz 3W |
|
Front protection |
IP55 |
|
Panel cut-out |
71 x 29 mm (WxH) |
|
Ambient temperature |
-10÷50°C |
Models with removable screw terminal blocks are available. In this case, the letter “S” of code changes in “Q”, ex. AT2-5BQ4E-AL.
All models come with an alarm buzzer.
Versions with 110V power supply are available.
On request, the AT2-5 is also available with gasket for a better protection between bezel and metal panel.
