VPB6D Vacuum Pump 6cfm Dual Voltage Ignition Proof Blackmax (CPS)

£613.91

In stock (can be backordered)

Suitable for Refrigerant Classes A1-A3. Refer to instructions for specific refrigerants.

Key Features
  • Dual Voltage Selector Switch:  115V 50Hz or 230V
  • Suitable systems containing: A1, A2, A2L and A3 refrigerants
  • Ultimate Vacuum Rating: 15 microns
  • Hardwired cable 3m
  • Advanced Air Cooled, Thermally Protected Motors Encased in Durable Aluminium Housing
  • Combination Oil Fill/Exhaust Cap
  • Large Double Sealed Oil Sight Glass
  • Easy Access Oil Drain Port
  • Gas Ballast Valve
  • Steel Inlet Port with Multiple Intake Sizes - 1/4", 3/8” and 1/2” SAE
  • Rubber Lined Handle
  • Skid Resistant Rubber Base

Tech Data Sheet

In stock (can be backordered)

Description

Technical Specifications:
Models VPB6D VPB12D
Stage 2-Stage 2-Stage
Ultimate Vacuum 25 Microns
Refrigerant System Classes A1 – Non-Toxic, Low Flammability
A2/L – Non-Toxic, Low Flammability
A3 – Non-Toxic, High Flammability
Dimensions 348mm x 140mm x 272mm 380mm x 160mm x 285mm
Weight 11.0 Kg 15.2 Kg
Free Air Displacement 151l / @ 50Hz 302l / @ 50Hz
Motor Size (HP) 1/2 HP 1 HP
2880 2880
Oil Capacity 540ml 590ml
Voltage Dual Voltage: 115V 60Hz / 230V 50Hz
Power Cord (Pump Connection) Hard Wired 3 Meter (Power Cord)
Power Switch Ignition Proof ON/OFF Switch
Operating Temperature Range 32°F to 125°F (0°C to 52°C)
Gas Ballast Valve YES
Intake Fittings Inlet Fitting with 1/4″, 3/8″ and 1/2″ SAE Male Ports



DOWNLOAD A COPY OF TECHNICAL DATA SHEET: CLICK HERE

Specification

Additional information

Weight 11.0 kg
Dimensions 38.5 × 18 × 32 cm
